| الاسم التجاري: | TIANKONGRC |
| رقم الطراز: | ح85 |
| الـ MOQ: | 10 قطعة |
| السعر: | 44.2USD |
| شروط الدفع: | باي بال، / تي تي، ويسترن يونيون، موني جرام |
| القدرة على التوريد: | 10000 قطعة/شهر |
Features:
High Torque and High Speed:
This servo offers outstanding performance at different voltages. At the rated voltage of 16.8V, the no-load speed reaches 0.08sec/60°, and the peak stall torque is as high as 85kg·cm. It can easily handle the complex operational requirements of RC climbing cars.
Full Metal Structure and Waterproof Design:
With a full metal casing and steel gears, the servo is robust and durable. The waterproof feature allows it to be used in harsh environments, effectively extending its service life.
Brushless Motor Drive:
Equipped with a brushless motor, it offers higher efficiency, lower noise, and a longer lifespan compared to traditional brushed motors.
High Precision and Fast Response:
With an operating frequency of 1520ms/333Hz and a dead zone width of only 2 microseconds, the servo can quickly and accurately respond to control signals.
Specifications:
| Operating Voltage | 8.4V | 10.4v | 12.8V | 15V | 16.8V |
| No Load Speed | 0.17sec/60° | 0.14sec/60° | 0.12sec/60° | 0.10sec/60° | 0.08sec/60° |
| Peak Stall Torque | 53kg·cm | 65kg·cm | 72kg·cm | 77kg·cm | 84kg·cm |
| Dimension | 40.0 x 20.0 x 40.5 mm | ||||
| Weight | 85g ± 5% | ||||
| Operating Temperature | -20℃ to 60℃ | ||||
| Operating Frequency | 1520ms/333Hz | ||||
| Dead Zone Width | 2usec | ||||
| Motor Type | Brushless | Gear Type | Steel gears with steel ball bearings | ||
Application :
